KNX Temperature Control
Στην παρούσα ενότητα παρουσιάζουμε τις λύσεις για τον έλεγχο ψύξης & Θέρμανσης. KNX Heating Actuators, KNX Temperature Sensors κα.
Pos.1 KNX Room Temperature Controller Smart 55.
The MDT Room Temperature Controller Smart 55 with integrated temperature and humidity sensor is used for controlling the temperature of indoor rooms.
SCN-RTR55S.01
Room Temperature Controller Smart 55, White glossy. Εξαιρετικά απλό για τον Χρήστη!
SCN-RTN55S.01 Room Temperature Extension Unit, Smart 55, White finish.
SCN-RTR55S06.01 Room Temperature Controller Smart 55, Black matt. Εξαιρετικά απλό για τον Χρήστη!
SCN-RTN55S06.01 Room Temperature Extension Unit, Smart 55, Black matt.
Switch actuators / heating actuators can controlled by the room temperature controller SCN-RTN55S along with thermal actuators or motorised KNX actuators. In addition, the MDT Room Temperature Controller Smart has 4 binary inputs for connecting floating contacts.
The extension unit can operated either as a second unit along with the SCN-RTR55S or as a stand-alone unit with the MDT Heating Actuator AKH (integrated temperature controller!).
Fits into Frames System55: White: GIRA Standard 55, E2, E22, Event, Esprit | BERKER S1, B3, B7 | JUNG A 500, A PLUS, A CREATION, AS 500, A550, A FLOW | MERTEN 1M, M-Smart, M-Plan, M-Pure. Black: GIRA E2 | BERKER B3, B7 | JUNG A550 | MERTEN M-Pure
- Active color display to indicate function and status.
- Background color w/b and display brightness adjustable.
- Display of set and actual temperature. For indoor temperature controlling. Range -10 to +50C.
- Selectable temperature controller (PI, two-position, PWM).
- 1 Bit +/-, 1 Byte or 2 Byte absolute object for setpoint adjustment.
- Setpoint values stored on bus voltage failure.
- Limit values min/max, frost protection alarm, min/max memory.
- Operation mode via Bit / Byte objects. Message when leaving the comfort zone.
- Temperature and humidly sensor with dew point calculation.
- 4 binary inputs to connect floating contacts (push-buttons or window/auxiliary contacts).
- Ventilation control by hand or automatic operation.
- 14 Byte object for plain text diagnostic.
- Installation in a box. Length of connection cables: 22cm. Integrated bus coupling unit
Pos.2 KNX Glass Room Temperature Controller Smart 55.
Glass Room Temperature Controller with automatic setpoint reduction based solar radiation.
SCN-RTRGW.02 Glass Room Temperature Controller Smart 55, with Temp Sensor. White.
SCN-RTRGS.02 Glass Room Temperature Controller Smart 55, with Temp Sensor. Black.
- Active color display to indicate function and status.
- Background color w/b and display brightness adjustable.
- Display of set and actual temperature.
- For indoor temperature controlling Range -10 to +50C.
- Selectable temperature controller (PI, two-position, PWM).
- Operation as room temperature extension unit possible.
- Simple setpoint adjustment via separate +/- buttons.
- 1 Bit +/-, 1 Byte or 2 Byte absolute object for setpoint adjustment.
- Setpoint values are stored on bus voltage failure.
- Limit values min/max, frost protection alarm, min / max memory.
- Operation mode can be set via Bit/Byte objects.
- Ventilation control by hand or automatic operation.
- 14 Byte object for plain text diagnostic. (WxH): 92x92mm
Pos.3 KNX Glass Central Operation Unit Smart.
The Central Operation Unit Smart combines a large number of functions in one device and serves as a central control unit for your smart home.
BE-GBZW.01 Glass Central Operation Unit Smart color display, White.
BE-GBZS.01S Glass Central Operation Unit Smart color display, Black.
BE-BZS86.01 Central Operation Unit Smart 86 color display, Plastic, White glossy.
BE-BZS8606.01 Central Operation Unit Smart 86 color display, Plastic, Black matt.
The integrated astronomical timer moves the blinds up in the morning automatically and down again after sunset. In addition, the outdoor lighting and the basic lighting can switched on in the house at sunset until midnight. All timer functions and switching times are individually adjustable. You can for example set the comfort temperature individually for all rooms, or activate automatic shading via the menu control. You can also lock your blinds for window cleaning or activate your KNX alarm system via the integrated code lock.
Four sensor surfaces are available for selected direct operating functions. Twenty further functions can controlled via menu and / or time switch. Overall, all functions can operated intuitively and conveniently with the 6 sensor surfaces. The large active colour display show indoor/outdoor temperature, temperature set points, date / time, sunrise / sunset, clear text and alarm messages are visualised. The Glass Central Operation Unit Smart is the ideal complement to the Glass Push-button II Smart.
- Comfortable room Temperature Controller with temp. sensor.
- Large, active color display (automatic brightness adjustment).
- Four direct operating functions (e.g. present, light, blinds).
- 20 operating functions via menu / time switch (e.g. dimmer /shutter /switching /send values /scenes /temperature set points).
- Code lock with 4-6 digits, to lock and unlock the device or alarm activation.
- Daily / weekly / astronomical time switch (20 channels each with 6 switching times).
- Holiday function with time period activation. Automatic calculation of public holidays.
- Ventilation control (manual or automatic).
- Visualization of inside/outside temperature, setpoint, time/date.
- Visualization of status information/messages (1Bit/14Byte)
- 6 status LEDs independently controllable. 6 logic blocks each with 4 inputs
- No additional power supply required. Installation in BOX. (WxH): 92x92mm
Pos.4 KNX Push Buttons with Temperature Sensor.
The MDT Push-button 55 is a KNX push-button with 2/4/6/8 button operation. By pressing a button, the push-button can call up parameterised functions such as scenes or the dimming function. A separate labelling field is available for the key functions.
White matt, LED +Temp Sensor.
Value For Money!
BE-TA55T2.02 (2-fold)
BE-TA55T4.02 (4-fold)
BE-TA55T6.02 (6-fold)
BE-TA55T8.02 (8-fold)
White glossy, LED +Temp Sensor.
BE-TA55T2.G2 (2-fold)
BE-TA55T4.G2 (4-fold)
BE-TA55T6.G2 (6-fold)
BE-TA55T8.G2 (8-fold)
Black matt, LED +Temp Sensor.
Value For Money!
BE-TA55T206.02 (2-fold)
BE-TA55T406.02 (4-fold)
BE-TA55T606.02 (6-fold)
BE-TA55T806.02 (8-fold)
Fits into Frames System55: GIRA Standard 55, E2, E22, Event, Esprit | BERKER S1, B3, B7 | JUNG A 500, A PLUS, A CREATION, AS 500, A550, A FLOW | MERTEN 1M, M-Smart, M-Plan, M-Pure
- Push-buttons can be programmed for 1 or 2 button operation.
- Integrated Temperature Sensor.
- Single- and double button operation for Switching, Dimming, Blinds, Values.
- 2/4/6/8 Operation/Status light LEDs (Red/Green) (No Leds on BE-TA550x.xx) and Orientation light independently controllable.
- Switch object to control the Led priority.
- Middle text field with cover foil for individual labelling
- Innovative group control with long / extra long operation.
- Value/Scenes toggle with up to 4 values.
- Short/long button push and 2 objects.
- 4 Logic blocks.
- Installation in box with included support ring. Integrated bus coupler.
Pos.5 KNX Room Temperature/Humidity Sensor 55 & Object Controller 55.
The MDT Room Temperature / Humidity Sensor 55 detects temperature and humidity in indoor rooms; the dew point is calculated automatically.
SCN-TFS55.01 Room Temp/Humidity Sensor 55, White glossy.
SCN-TFS5506.01 Room Temp/Humidity Sensor 55, Black matt.
Min / max limit values can be set for the sensors during the parameterisation of the device and corresponding actions can be defined in case of deviation. The comfort range of the room climate is defined using Min / Max values when parameterising the room temperature / humidity sensor.
Fits into Frames System55, White: GIRA Standard 55, E2, E22, Event, Esprit | BERKER S1, B3, B7 | JUNG A 500, A PLUS, A CREATION, AS 500, A550, A FLOW | MERTEN 1M, M-Smart, M-Plan, M-Pure. Black: GIRA E2 | BERKER B3, B7 | JUNG A550 | MERTEN M-Pure
- Room temperature sensor for indoor rooms. Range -10 to +50C
- Humidity sensor with dew point calculation. Message when leaving the comfort zone.
- Min/max limits and value memory.
- Installation in an installation box with included support ring.
- Recommended installation height: 1.6m
- Integrated bus coupling unit.
SCN-RTR55O.01 Object Controller 55, White glossy
SCN-RTR55O06.01 Object Controller 55, Black matt
The comfort range of the room climate is defined using Min / Max values when parameterising the object controller. Switch actuators / heating actuators can be controlled by the object controller along with thermal actuators or motorised KNX actuators. Details as above + :
- Selectable temperature controller (PI, two-position, PWM).
- 1 Bit +/-, 1 Byte 2 Byte absolute object for setpoint adjustment. Setpoint values are stored on bus voltage failure.
- Limit values min/max, frost protection alarm, min / max memory. Operation mode can be set via Bit / Byte objects.
- Temperature and humidity sensor with dew point calculation.
- 4 binary inputs to connect floating contacts (push-buttons or window / auxiliary contacts).
- Ventilation control by hand or automatic operation.
- 14 Byte object for plain text diagnostic. length of connection cables: 22 cm.
Pos.6 KNX Temperature Controllers & PT1000 Sensors.
The MDT Temperature Controller is used for all purpose temperature control applications.
SCN-RT8REG.02 Temperature Controller 8-fold, 2SU MDRC.
SCN-RT6AP.01 Temperature Controller 6-fold, Surface mounted, for PT1000 sensors up to 12m cable length.
SCN-RT2UP.01 Temperature Controller 2-fold, Flush mounted, for PT1000 sensors up to 12m cable length.
SCN-RT4UP.01 Temperature Controller 4-fold, Flush mounted, for PT1000 sensors up to 12m cable length.
Accessories / Sensors for SCN-RTxAP/UP.01
SCN-PTST1.01 PT1000 Sensor, Dimensions 4x30mm, 1m cable.
SCN-PTST3.01 PT1000 Sensor, Dimensions 6x50mm, 3m cable.
SCN-PTAN3.01 PT1000 Sensor Strap on installation, Dimensions 8x40mm, 3m cable.
SCN-PTDE0.01 PT1000 Sensor ceiling installation, Cut out Diameter: 23mm Depth: 28mm.
The temperature is received as an KNX object or directly from the connected PT1000 temperature sensors (only SCN-RT6AP.01, SCN-RT2UP.01 or SCN-RT4UP.01).
- Selectable temperature controller (PI, two-step, PWM).
- Limit values min/max.
- Frost-/heat protection alarm.
- Min/max memory.
- Cyclical sending of contact state programmable.
- Day-/night-/frost-/heat protection operation, cooling function.
- Status feedback by HVAC and RHCC status objects.
- Operation mode can be set via Bit/Byte objects.
- Integrated bus coupling unit.
Pos.7 KNX Heating Actuators MDT AKH Series.
The MDT Heating Actuator AKH has an integrated PI controller for heating and cooling each channel. To control the heating, the actuator receives the room temperature. Up to 4x230VAC (3x24VAC) electrothermal actuators can be connected and controlled at each of the non-wearing outputs.
AKH-0400.03 Heating Actuator 4-Fold, 2SU MDRC, control electrothermic valve drives 24-230VAC
AKH-0600.03 Heating Actuator 6-Fold, 3SU MDRC, control electrothermic valve drives 24-230VAC
AKH-0800.03 Heating Actuator 8-Fold, 4SU MDRC, control electrothermic valve drives 24-230VAC
- New generation with function extension.
- Each channel controls up to 4 electrothermic valve drives (230VAC).
- Free assignment of the outputs to the controller channel.
- Controllable with 1 Bit (switching / PWM) / 1 Byte actuating variable or direct control with temperature value via KNX bus.
- Integrated PI temperature controller (heating and cooling).
- Comfort-, night- and frost protection, summer- / winter operation.
- 1 Bit +/-, 1 Byte or 2 Byte absolute object to set the given value.
- Setpoint values are stored on bus voltage failure.
- Emergency operation if cyclic actuating variable fails.
- Overload protection with fault message object (230VAC).
- Mains voltage failure detection with fault message object (230VAC).
- Objects for heating request and cyclic movement of the valves.
- Comprehensive scene functions.
- Compatible with many visualizations. Minimum flow temperature.
- Diagnostics for each channel with 14 Byte plain text object.
- Quick application download (long frame support with ETS 5 or higher).
- Production in Germany, certified according to ISO 9001
Pos.8 KNX Heating Actuators with Fan Coil Operation MDT AKK Series.
AKK-04FC. 4-channel Switch Actuator offers the additional “fan coil” function. This enables the control of fans or ventilator convectors with up to 4 levels.
AKK-03UP. Flush Switch Actuator offers the additional “fan coil” function. This enables control of fans or ventilator convectors with up to 3 levels.
AKK-03UP.03 Switch Actuator, 3-fold with Fancoil operation, Flush, 230VAC, 10A Εξαιρετική Επιλογή
AKK-04FC.03 Switch Actuator, 4-fold with Fancoil operation, 2SU, 230VAC, 10A Εξαιρετική Επιλογή
- Fan Coil mode:
- Control of 3/4-speed fans / ventilator convectors
- Outputs are interlocked
- Direct operation by three 1 Bit objects or a single 1 Bit object (+/-)
- Automatic operation by 1 Byte control value (0-100 %)
- Suitable for 2-pipe systems and 4-pipe systems
- Output objects to control valves for heating/cooling
- Day / Night function to limit fan speed at night
- Emergency operation if variable fails
- Production in Germany, certified according to ISO 9001
- Switch Actuator mode:
- NO and NC contact operation. | Time functions (switch-on /switch-off delay). | Staircase light function with adjustable warning time. | Status response (active / passive) for each channel. | Logical linking of binary data, 8 scenes per channel. | Central switching functions and blocking for forced operation. | Adjustable behavior in case of bus voltage return. | Quick application download (long frame support with ETS 5 or higher).
Pos.9 KNX Room Temperature Controller / Sensor 55.
The MDT Room Temperature Controller 55 is used for detecting the temperature of indoor rooms and controlling this.
SCN-RT1UP.01 Room Temperature Controller, White matt.
SCN-RT1UP.G1 Room Temperature Controller, White glossy.
SCN-TS1UP.01 Room Temperature Sensor, White matt.
SCN-TS1UP.G1 Room Temperature Sensor, White glossy.
SCN-RT1UPE.01 Room Temperature Controller with adjustment knob, White matt.
SCN-RT1UPE.G1 Room Temperature Controller with adjustment knob, White glossy.
It is used in combination with an MDT Actuator AKU or heating actuators without an integrated controller.
The MDT Room Temperature Sensor 55 records the temperature and makes it available to other units such as the MDT Heating Actuator AKH. The temperature measuring range is between -10 and 50 °C.
Fits into Frames System55: GIRA Standard 55, E2, E22, Event, Esprit | BERKER S1, B3, B7 | JUNG A 500, A PLUS, A CREATION, AS 500, A550, A FLOW | MERTEN 1M, M-Smart, M-Plan, M-Pure
- Selectable temperature controller (PI, two-position, PWM).
- Setpoint value is stored on voltage failure. Bit/Byte object to set the given value.
- For indoor temperature controlling, range -10° to +50 °C.
- Limit values min/max, Frost protection alarm, Memory for min / max.
- Day-/night-/frost-/ heat protection operation.
- Operation mode can be set via Bit/Byte objects.
- Integrated bus coupling unit.
