KNX Inputs
Τα KNX Inputs είναι υλικά απο τα οποία μπορούμε να πάρουμε πληροφορίες στο KNX.
Pos.1 KNX Binary Inputs.
The MDT Binary Input makes conventional push-buttons, switches, window and auxiliary contacts “smart” for KNX. The application provides the suitable parameters for various applications. Versions for floating contacts, 24VAC/DC and 230VAC are available.
BE-04000.02
Binary Inputs 4-fold, 2SU MDRC, Inputs for potential free contacts
BE-04024.02 Binary Inputs 4-fold, 2SU MDRC, Inputs 24VAC/DC
BE-04230.02 Binary Inputs 4-fold, 2SU MDRC, Inputs 230VAC
BE-08000.02 Binary Inputs 8-fold, 4SU MDRC, Inputs for potential free contacts
BE-08024.02 Binary Inputs 8-fold, 4SU MDRC, Inputs 24VAC/DC
BE-08230.02 Binary Inputs 8-fold, 4SU MDRC, Inputs 230VAC
BE-16000.02 Binary Inputs 16-fold, 8SU MDRC, Inputs for potential free contacts
BE-16024.02 Binary Inputs 16-fold, 8SU MDRC, Inputs 24VAC/DC
BE-16230.02 Binary Inputs 16-fold, 8SU MDRC, Inputs 230VAC
BE-32000.02 Binary Inputs 32-fold, 12SU MDRC, Inputs for potential free contacts.
Value For Money!
- Comprehensive function extension.
- To connect push-buttons or window / auxiliary contacts.
- New multi-touch function, sends up to 4 values / DPTs on the same or diffrent objects.
- Innovative group control with long / extra long button press.
- 4 integrated logic modules, e.g. evaluation of the inputs (e.g. window closed or sending second object).
- NO or NC contact operation, sending contact status.
- Operation of blinds and shutters, 1 and 2 button operation.
- Forced setting function for each output.
- Scenes, block objects for each channel.
- Operation with short / long button push and 2 objects.
- Integrated pulse and switching counters with extensive counter functions (suitable for 30 ms S0 pulses).
- Cyclical sending, sending after reset.
- Internally generated contact voltage of 12V.
- Production in Germany, certified according to ISO 9001.
Pos.2 KNX Binary Inputs Flush Universal Interfaces.
The MDT Universal Interface makes conventional push-buttons, switches, window and auxiliary contacts “smart” for KNX. The application provides the suitable parameters for various applications. Versions for floating contacts, 24VAC/DC and 230VAC are available.
BE-02001.02 Universal Interface 2-fold Flush, connect potential free contacts, with LED output. Εξαιρετική Επιλογή
BE-04001.02 Universal Interface 4-fold Flush, connect potential free contacts, with LED output. Εξαιρετική Επιλογή
BE-06001.02 Universal Interface 6-fold Flush, connect potential free contacts, with LED output
BE-02230.02 Universal Interface 2-fold Flush, for 230VAC signals
- To connect push-buttons or auxiliary contacts.
- Each input can be set as 1,5 mA low current output for LED (Not with BE-02230.01).
- New multi-touch function, sends up to 4 values /DPTs same or different objects.
- Innovative group control with long / extra long button press.
- 4 integrated logic modules, e.g. evaluation of inputs (e.g. window closed or sending second object).
- NO or NC contact operation, programmable length of button push.
- Dimming and shutter function for 1 and 2 button operation.
- Forced setting function and switching commands for each output.
- Short / long button push with 2 objects.
- Integrated pulse and switching counters with extensive counter functions.
- Cyclical sending of contact state programmable.
- Flush mounted (length of cables:22cm). (WxHxD): 41mm x 41mm x 12mm.
- Integrated bus coupling unit.
- Production in Germany, certified according to ISO 9001
Pos.2 KNX Analog In & Output.
The MDT Analog In / Output AIO is suitable for controlling devices with 0-10 V input and for recording 0-20 mA (4-20 mA) / 0-10 V measurement data (e.g. from fill-level or pressure sensors). Each channel can be configured both as an input and as an output and is galvanically separated from the KNX bus.
AIO-0210V.01 Analog In-/Output 2-fold, Flush mounted, Input Voltage 0-10V/2-10V or Current Loop 0-20mA/4-20mA, Output Voltage 0-10V
AIO-0410V.01 Analog In-/Output 4-fold, 2SU MDRC, Input Voltage 0-10V/2-10V or Current Loop 0-20mA/4-20mA, Output Voltage 0-10V
- Each channel can be configured independently (in / output)
- In / outputs are galvanically-isolated from the bus
- In / outputs are galvanically-connected together
- Voltage for output operation is generated inside the actuator.
- No external power supply required
- Input operation 0-10V / 2-10V or 0-20mA / 4-20mA (switchable). Conversion of measuring unit and DPT can be parameterized. Min/max function, wire breakage detection. Threshold and traffic light function.
- Output functions 0-10 V: Control by 1 Byte, 2 Byte float or 1 Bit objects. Day/night function to limit control value. Emergency mode if given value fails
- Flush mounted version: installation BOX. (WxHxD): 41mm x41mm x 12mm
- Quick application download (long frame support with ETS5 or higher)
- Production in Germany, certified according to ISO 9001
